Permanet magnet lifter: PML-1000
Magnetic lifter has strong magnetic strengh produced by NdFeB magnet. The lifters have the features of strong attraction,smaller volume,lighter weight,powerful lifting effort,easy and safe to operate ,long-period effort and without power supply.
They are been used to lift and transport the steel and iron for factories,docks,ware houses,transportation etc.
Now We can supply a range of lifting magnets, with a lifting capacity mainly from 100 kg to 6000 kg.
|
Model |
Rated lifting capacity(kg) |
Max breakaway force(kg) |
Size (mm) |
Nw(kg) |
||
|
L |
W |
H |
||||
|
PML-100 |
100 |
350 |
92 |
65 |
69 |
2.5 |
|
PML-300 |
300 |
1050 |
165 |
95 |
95 |
9.5 |
|
PML-500 |
500 |
1750 |
235 |
115 |
116 |
21 |
|
PML-600 |
600 |
2100 |
235 |
115 |
116 |
21 |
|
PML-1000 |
1000 |
3500 |
310 |
135 |
140 |
42 |
|
PML-2000 |
2000 |
7000 |
394 |
170 |
205 |
100 |
|
PML-3000 |
3000 |
10500 |
580 |
214 |
215 |
190 |
|
PML-5000 |
5000 |
17500 |
600 |
235 |
290 |
295 |
|
PML-6000 |
6000 |
21000 |
800 |
235 |
290 |
395 |
